Description:
Adding the green high temperature resistant pigment into the polyamide acid to form a film, the overall appearance of green, uniform color distribution. It has the same property as CN type, heating-resistant, radiation resistant, stable chemical reaction. We can supply 25um thickness. It is applied to high temperature insulating tape, label or protection film and so on.
Features:
Green, it has the same property as CN type, environment-friendly with halogen free, meet EU environmental standard such as RoHs, Reach.
Size:
1、Thickness:25μm.
2、Width:520mm.
Property parameter table:
性能Property | 单位Unit | CG251 | 测试方法 Test Method |
厚度Thickness | μm | 25±3 | ASTM D374 |
宽度 Width | mm | 520 | ASTM D374 |
拉伸强度 Tensile Strength | 纵MD | Mpa | ≥120 | ASTM D882 |
横TD | Mpa | ≥100 | ASTM D882 |
断裂伸长率 Elongation | 纵MD | % | ≥25 | ASTM D882 |
横TD |
| ≥40 | ASTM D882 |
绝缘强度 Dielectric Strength | KV | ≥1.5 | ASTM D149 |
耐温性Operating temperature | ℃ | 短期400℃,长期260℃ Short-term 400℃,260℃ for long time | ASTM D5213 |
The above data are for reference only.
Application:
It Is applied to green heating resistant tape, high temperature color adhesive tape, green heating resistant label, heating resistant protective film and other special application.
